| Form Factor | Tabletop |
| Display | 1 x Touchscreen |
| Channels of I/O | Analog: 8 Input / 2 Output at 44.1 kHz |
| Max Sample Rate/Resolution | 44.1 kHz / 16-Bit |
| Number of Mic Preamps | 6 |
| Input Level Adjustment | 6 x via Touchscreen |
| Number of Headphone Mixes | 1 x Master 5 x Guest |
| Solo/Mute | Mute per Input Channel |
| Pad | None |
| Sample Pads | 9 x Assignable |
Connectivity
| Analog Audio I/O | 6 x XLR 3-Pin Balanced Mic Input 6 x 1/8" / 3.5 mm TRS Unbalanced Headphone Output 2 x 1/4" TRS Balanced Monitor Output 1 x 1/8" / 3.5 mm TRRS Unbalanced Aux In/Out |
| Phantom Power | +48 V, Selectable On/Off (Selectable on Individual Inputs) |
| Digital Audio I/O | None |
| Host Connection / USB | 1 x USB Type-C (Class-Compliant USB 2.0) |
| Memory Card Slot | 1 x SDXC |
Performance
| Frequency Response | 20 Hz to 20 kHz �1 dB (at 44.1 kHz) |
| Gain/Trim Range | Mic Inputs: 0 dB to +70 dB |
| Max Input Level | XLR Mic Inputs: +5 dBu for 0 dBFS 1/8" / 3.5 mm Aux Inputs: +2.5 dBu |
| Max Output Level | Monitor Outputs: +5.5 dBu |
| Headphone Output Power | 20 mW per Channel into 32 Ohms |
| Impedance | XLR Mic Inputs: 3 Kilohms 1/8" / 3.5 mm Aux Inputs: 3 Kilohms 1/4" Monitor Outputs: 320 Ohms 1/8" / 3.5 mm Headphone Outputs: 27 Ohms |
| EIN | -124 dBu (150-Ohm Source, +70 dB Gain) |
Digital Audio
| Sample Rates | 44.1 kHz |
| Bit Depths | 16-Bit |
Compatibility
| OS Compatibility | macOS Windows iOS |
| Included Software | None |
| Compatible Software (Not Included) | Any Core Audio (Mac) Compliant Software |
| Required Hardware | Available USB 2.0 Port USB Cable (Not Included) |
Power
| Power Requirements | AC/DC Power Adapter (Included), Battery, or USB Bus Power |
| AC/DC Power Adapter | 5 VDC at 1 A |
| Power Consumption | 5 W |
| Battery Type | 4 x AA |
| Approximate Battery Life | 2 Hours (AA Alkaline, Phantom Off, Recording, with Headphones) 3.5 Hours (AA NiMH, Phantom Off, Recording, with Headphones) 6.5 Hours (AA Lithium, Phantom Off, Recording, with Headphones) |
Physical
| Anti-Theft Features | Kensington Security Slot |
| Dimensions | 11.6 x 9.8 x 2.4" / 29.5 x 24.8 x 6.1 cm |
| Weight | 3.1 lb / 1.4 kg |
